Tahiti Lock
1 / 5
RFID Tag Car Access Control/Smart Parking System
Product Description
Basic Information
Falling Prevention
Pull-Type
Vehicle Inlet
Up
Design
Single Post
Certification
CE
Voltage
DC 12V
Product Name
Tag RFID Car Access Control/Smart Parking System
ODM/OEM
Yes, Accepted
Warranty
At least 1 Year
Origin
China
HS Code
847190
Main Features
Utilizing ARM chip technology, TCP/IP network integration, and a real-time embedded OS, this system leads the parking management industry into a digital IP age.
Full TCP/IP Network
Includes WEB Server and PC charging terminals using a classical CS framework. Control terminals can be accessed via any PC in the LAN.
Multi-Park Management
Supports up to 16 respective parks or zones with independent access authorization, charge rates, and statistical data.
Real-Time Intercom & Voice Prompt
Features unambiguous two-way intercom and onboard digital audio for synchronous voice tips and LED display prompts.
Auto-Switch Online/Offline
Supports standalone operation when disconnected; data uploads automatically once the connection is restored.
Various RFID Support
Compatible with 13.56MHz Mifare, 125KHz EM, 900MHz long range, and 2.4GHz Bluetooth cards.
Technical Specifications
| Working Voltage | DC12V |
| Working Temperature | -30 to 70 degree |
| Output Relay | 4 |
| I/O Interface | 4/4 |
| RS232/RS485 | 2/1 |
| Simulate ADC/DAC | 2/0 |
| Wiegand 26 Interface | 2 |
| Network Communication | TCP/IP |
| Memorable Card Information | 20,000 |
Product Showcase
Frequently Asked Questions
How many parking zones can the system manage?
The system supports management for up to 16 independent parking zones, each with its own charge rates and access rules.
What types of RFID cards are supported?
It supports a wide range of RFID technologies including 13.56MHz Mifare, 125KHz EM cards, 900MHz long-range ID cards, and 2.4GHz Bluetooth cards.
Does the system work if the server goes offline?
Yes, the system features an auto-switch mode. It can work offline independently and will automatically upload all data once the connection is restored.
Can the system software be upgraded on-site?
Yes, the system supports field upgrading or online updates via software to add new functions or modify voice prompts.
What is the communication architecture of the system?
The system uses a full TCP/IP communication network with a classical CS framework, ensuring stable and real-time data transmission across the LAN.
Is there a voice prompt or intercom feature?
Yes, it includes real-time two-way intercom and onboard digital audio for synchronized voice prompts and LED display information.
